Lancer Extruder & runout sensor by Peopoly
$69.99
Lancer Extruder & runout sensor by Peopoly
$69.99
The Peopoly Lancer Extruder is a state-of-the-art, high-performance extruder designed for precision, durability, and ease of use. Perfect for a wide range of 3D printing applications, the Lancer Extruder combines innovative design with robust engineering to deliver exceptional results.
this extruder bolts on to any existing Orbiter 2 mounts
Design & Build
- Metal Body Design: Weighing only 149g, the Lancer Extruder features a lightweight yet sturdy metal body for stability and reduced wear and tear.
- Compact Size: A smaller, more compact design for easier integration into various 3D printer setups.
- Precision CNC Machined Metal Body: High assembly precision and long service life, thanks to pure CNC machining.
- Optimized Motor Position: Simplifies assembly and maintenance, enhancing overall usability.
- 11mm Short Driver Gears: Designed for optimal performance, ensuring smooth and reliable filament extrusion.
- Hardened Metal Filament Driver Gears: Enhanced durability for long-term use, even with abrasive filaments.
- High-Precision Machined Secondary Drive Gear Set: Ensures smooth and accurate filament driving for consistent printing quality.
- Maximum Extrusion Force of 90 Newtons: Powerful extrusion capabilities to handle a wide range of filament types with ease.
- Adjustable Tension Mechanism:Allows fine-tuning of grip strength with a fixed capture screw for optimal filament handling.
- Convenient Lever Design: Easy loading and unloading of filament with a user-friendly lever mechanism.
- Better Aligned Filament Path: Ensures smooth and trouble-free filament feeding.
- New Generation PTFE Input Coupler:Designed for improved filament guidance and reduced friction.
- All-Metal Filament Guide: Highly resistant to wear when using carbon fiber and other abrasive materials.
Links:
Reference Klipper config:
rotation_distance: 4.637
microsteps: 16
full_steps_per_rotation: 200
nozzle_diameter: 0.400
filament_diameter: 1.75
interpolate: false
run_current: 0.8
hold_current: 0.5
sense_resistor: 0.110
stealthchop_threshold: 100
