5015 blower fan by HoneyBadger
$9.99
5015 blower fan by HoneyBadger
$9.99
What is it:
After careful testing and multiple rounds of samples we are ready to release our HoneyBadger P-Series fans. This 5015-blower fan has a durable fan motor and can take a beating on your printer with its Class A insulation rated up to 95C its sure to survive an enclosed environment.
Specs:
PWM version (2 wire)
Construction type: Dual ball bearing
- Construction type: Dual ball bearing
- Operating Voltage: 12~26.5 (VDC)
- Voltage: 24V
- Input Power: 1.68(W)±15%
- Speed: 6400 (RPM) ±10%
- Max Air flow: 4.15 (CFM)
- Max Air Pressure 29.18 (mmH2O)
- Insulation Class A (95℃)
3 wire PWM version (only runs 100% or OFF unless using a 3 wire/pin connector)
- Voltage: 24V
- Operating Voltage: 12~26.5 (VDC)
- Max Air flow: 5.41 (CFM)
- Max Air Pressure: 36.45 (mmH2O)
- Noise: 43.2 (DB)
- Input Power: 2.64(W)±15%Speed: 7300 (RPM) ±10%
- Insulation: Class A (95℃)
- Red is positive, Black is Negative, blue is PWM
-
Construction type: Dual ball bearing
4 wire 9200 rpm 24-28V with tach and pwm
- Operating voltage 12-26.5V 0.19A
- Max RPM 9200 RPM
- Max Flow 5.68CFM
- Max Pressure: 57.4 mmH2O
- noise: 48DB
- Insulation: Class A (95℃)
- Red is positive, Black is Negative, blue is PWM, White is Tach
Backed by our 45-day no questions asked return policy.
