What is it


3DO ASA is a UV-resistant and weatherproof copolymer designed for industrial uses.
It has a high level of process dependability and is well suited for mechanically stressed components. It's an electrically insulating substance.
The layer adhesion, thermal stability, flow characteristics, and warping tendencies of 3DO ASA have all been optimized.
The raw material has been authorized in accordance with REACH, RoHS, and FDA regulations.

  • Nozzle: 230-250°C
  • Heatbed: 100-110°C

This product has 15% carbon fibers, it's recommended to use a >0.5mm harden steel nozzle like the bozzle

Colour - Carbon Black



  • Made in EU
  • Good strength
  • Good mechanical properties
  • Good chemical resistance
  • Flame retardant (UL94 HB)
  • RoHS, Reach, FDA compliant

Properties

Method

Unit

Value

Tensile modulus (E-Modulus)

ASTM D882

MPa

2200

Tensile strength

ASTM D882

MPa

49

Flexural strength

ASTM D882

MPa

78

Nominal elongation at break

ASTM D882

%

20

Notched impact strength

ASTM D256

kj/m²

140 @ 23°C
 29 @ -30°C

VICAT A (VST)

ASTM E2092

°C

96*

Melting temperature

ISO 3146-C

°C

180-200

MFR

ASTM D1238

g/10min

20

Shrinking

ASTM D955

%

0,4

Density

ASTM D792

g/cm³

1,05
